All Dimensions are in mm and are of the cased unit.
N/F = not fitted.
CODE A B C D E F G H I J ERP BAND STANDING LOSS
ET180P5 1297 1258 1211 948 560 635 780 850 970 N/F B 58
ET210P5 1485 1446 1399 1136 665 740 885 955 1075 1150 C 70
ET250P5 1735 1696 1649 1386 830 905 1070 1130 1250 1400 C 81
ET300P5 2048 2009 1962 1699 859 934 1100 1159 1279 1600 C 92
For Twin Zone codes please replace P5 with PT5
40.0˚
45.0˚
15.0˚
25.0˚
35.0˚
50.0˚
45.0˚
18
J I H F EG D C B A
STAINLESS UV - SOLAR INDIRECT SYSTEM FIT PRE-PLUMBED
For Twin Zone codes please replace P5 with PT5
CODE A B C D E F G H I J ERP BAND STANDING
LOSS
EN120P5 922 883 836 573 171 246 400 470 590 N/F B 47
EN150P5 1109 1070 1023 760 211 286 440 508 628 N/F B 54
EN180P5 1297 1258 1211 948 211 286 620 690 810 N/F B 58
EN210P5 1485 1446 1399 1136 246 321 620 690 810 1150 C 70
EN250P5 1735 1696 1649 1386 246 321 620 690 810 1400 C 81
EN300P5 2048 2009 1962 1699 246 321 670 784 904 1600 C 92
40.0˚
45.0˚
15.0˚
25.0˚
35.0˚
50.0˚
45.0˚
STAINLESS UV - INDIRECT SYSTEM FIT PRE-PLUMBED
J I H G F E D C B A
23
STAINLESS UV
UNVENTED HOT WATER CYLINDERS
