TECHNICAL SPECIFICATIONS
Element Rating 3kW 240 V
Thread Type 1 3/4” BSP
Fuse Requirement 13A via Double Pole Switch
Control Thermostat for Element - Temperature Range 45
o
C - 65
o
C
High Limit Thermostat for Element - Temperature Set Point 85
o
C
Maximum Inlet Water Pressure 12 Bar
Operating Pressure 3.0 Bar
Expansion Valve Opening Pressure 6.0 Bar
Expansion Vessel Charge Pressure 3.0 Bar
Maximum Operating Pressure 5.5 Bar
Opening Pressure of T & P Valve 7.0 Bar
Opening Temperature of T & P Valve 90
o
C
Maximum Pressure on Primary Circuit (Indirect & Solar Coil) 3.5 Bar
PRESSURE SPECIFICATIONS
IMMERSION ELEMENT SPECIFICATIONS
PRODUCT CODE
WEIGHT EMPTY
WEIGHT FULL
CAPACITY
Designated Solar
Volume
Fossil Fuel Volume
HEAT-UP TIME
70% RE-HEAT TIME
INDIRECT COIL
SURFACE AREA
INDIRECT COIL
CAPACITY
INDIRECT
COIL kW RATING
SOLAR COIL
SURFACE AREA
SOLAR COIL
CAPACITY
Heat Loss (kW/24Hr)
DIRECT SLIMLINE
EDS90 29 120 90 - - 80m - N/A N/A N/A N/A N/A 1.05
EDS120 38 160 120 - - 105m - N/A N/A N/A N/A N/A 1.12
EDS150 46 200 150 - - 125m - N/A N/A N/A N/A N/A 1.29
EDS180 54 235 180 - - 140m - N/A N/A N/A N/A N/A 1.37
EDS210 60 270 210 - - 160m - N/A N/A N/A N/A N/A 1.64
INDIRECT SLIMLINE
ENS90 36 130 90 - 17m 22s 15m 12s 0.67 3.69 16.1 N/A N/A 1.05
ENS120 44 165 120 - 25m 01s 16m 25s 0.67 3.69 19.0 N/A N/A 1.12
ENS150 52 205 150 - 26m 24s 19m 37s 0.77 4.26 19.5 N/A N/A 1.29
ENS180 60 240 180 - 32m 14s 23m 05s 0.77 4.26 20.4 N/A N/A 1.37
ENS210 68 280 210 - 36m 36s 27m 40s 0.77 4.26 23.4 N/A N/A 1.64
DIRECT
ED90 25 115 90 - - 85m - N/A N/A N/A N/A N/A 0.99
ED120 30 150 120 - - 110m - N/A N/A N/A N/A N/A 1.13
ED150 35 185 150 - - 135m - N/A N/A N/A N/A N/A 1.30
ED180 40 220 180 - - 160m - N/A N/A N/A N/A N/A 1.40
ED210 45 255 210 - - 185m - N/A N/A N/A N/A N/A 1.68
ED250 50 300 250 - - 225m - N/A N/A N/A N/A N/A 1.95
ED300 55 355 300 - - 270m - N/A N/A N/A N/A N/A 2.20
INDIRECT
EN120 35 155 120 - 23m 47s 18m 00s 0.67 3.69 18.35 N/A N/A 1.13
EN150 40 190 150 - 29m 36s 20m 35s 0.77 4.26 19.07 N/A N/A 1.30
EN180 45 225 180 - 31m 58s 22m 47s 0.77 4.26 20.28 N/A N/A 1.40
ENI210 50 260 210 - 33m 05s 26m 16s 0.86 4.83 23.08 N/A N/A 1.68
EN250 55 305 250 - 41m 18s 28m 20s 0.86 4.83 24.40 N/A N/A 1.95
EN300 60 360 300 - 46m 01s 32m 52s 0.86 4.83 24.87 N/A N/A 2.20
31
STAINLESS UV
UNVENTED HOT WATER CYLINDERS
