±(3.0% + 5D)
Resistor / Continuity
Overload Protection : AC1000Vrms, 1000Vdc
Maximum Open Voltage : 1.6V
Continuity : Built-in buzzer sounds when measured resistance
is less than 25Ω and sounds off when measured resistance is
more than 400Ω, Between 25Ω to 400Ω the buzzer maybe
sound or off either.
0Ω ~ 10kΩ
1Ω
±(0.9% + 2D)
Range Resolution Accuracy
Diode
Overload Protection : AC1000Vrms、1000Vdc
AC Current
Adjacent Conductor Influence : <0.08A/A
Frequency Response : 50 ~ 60Hz (Sine Wave)
VoltSense
80V ~ 1000V AC with 50Hz ~ 60Hz
1.5A ~ 200.0A
0.1A
0.4V ~ 0.8V 0.1V ±(1.0% + 3D)
Range Resolution Accuracy
Range Resolution Accuracy
EN
A5AR
