Apple Desktop Computer - Page 45

CHAPTER 4
RAM Expansion
The Expansion Slots 45
Removing the Retaining Screws 4
A slot-shaped handle is located at the back end of the logic board assembly. The
retaining screws are located inside the slot in the handle, as shown in
Figure 4-3.
Figure 4-3 Logic board assembly handle and retaining screws
Handle
Retaining screws
