iBook (14.1 LCD 16 VRAM) Take Apart
Bottom Shield
Procedure
1. With the computer on a soft cloth, remove the following screws from the bottom shield:
• nine identical 6-mm long Phillips screws (two of the screws may be concealed
under foil tape at the display hinge)
• two identical 14.5-mm long Phillips screws
• one 5-mm long Phillips screw
