8 Chapter 1 Welcome
iPod Hi-Fi Front View
Note: You can use your iPod Hi-Fi with the speaker grille on or off. To best protect the
speakers, leave the grille on. To avoid damage to the speakers, do not touch the
speaker cones.
Tuned bass reflex ports
Woofer
iPod connector Volume control buttons
Wide-range driver
Wide-range driver
Status light
Infrared (IR)
receiver
Removeable speaker grille
