Testing Procedures - 21
iPod mini
STATUS
1. The screen may show:
• XXXXXLCD = LCD vendor
• HP (Headphones): HP OK = Connected, NO HP = Not connected
• NO FWPW = No FireWire Power (or FWPW OK = FireWire cable connected)
• NO USBPW = No USB Power (or USBPW OK = USB cable connected)
• NO CHGR = Not Charging (or CHGRING = if FireWire or powered USB cable
connected)
2. Pass condition = iPod behaves as indicated.
DRV TEMP
1. The screen will show:
• CUR = Current temperature
• MIN = Minimum temperature
• MAX = Maximum temperature
2. Pass condition = CUR temperature must be between the MIN and MAX values.
STATUS
WINTKLCD
HP OK
NO FWPW
NO USBPW
NO CHGR
DRV TEMP
CUR : 35C
MIN : 24C
MAX : 47C
