MacBook Pro (13-inch) General Troubleshooting — Apple Service Diagnostic (ASD) 30
2010-09-14
Apple Service Diagnostic (ASD)
Run Apple Service Diagnostic to determine if any of the thermal sensors are malfunctioning.
When sensors fail, replace the corresponding part —logic board, battery, or top case. See chart
below for correlation between error code and part.
Name Location
TC0D Logic board
TC0P Logic board
Th1H Logic board
TN0D Logic board
Ts0P Trackpad ex cable
TB0T Battery
TB1T Battery
TB2T Battery
TB3T Battery
Clamshell Service Diagnostic (CSD)
Clamshell Service Diagnostic (CSD) is a diagnostic tool that checks Apple’s latest portable
computers for the presence of AirPort, Bluetooth, LCD and Ambient Light Sensor (ALS) to assist
you in quickly making a failure determination.
Troubleshooting benets of using CSD include:
• Quick way (less than 1 minute) to determine whether clamshell-related modules (AirPort,
Bluetooth, LCD and ALS) are electrically connected without taking apart the system.
• Results of CSD can help pinpoint if any clamshell cables may need to be reseated to logic
board.
• Diagnostic results can help isolate a video or wireless issue to either clamshell or logic
board, to avoid unnecessary replacements of these components.
In the MacBook Pro (13-inch), CSD checks for the presence of the computer’s:
• AirPort
• Bluetooth
• LCD
• Ambient Light Sensor (ALS)
CSD does not check for the presence of the computer’s:
• iSight camera
• externally connected hardware components (such as USB or FireWire devices)
CSD does not check for issues with the OS X or other software-related problems such as
application or extension conicts.
For more information, and to download CSD, refer to:
kBase #CP1100: Notebook Computer Clamshell Screening Process
