MacBook (13-inch, Late 2009) Basics — Updates 8
2010-06-15
Troubleshooting
• Symptom Charts: Input/Output Devices: Revised trackpad steps in Deep Dive to refer to
trackpad grounding strap procedure
• Symptom Charts: Input/Output Devices: Revised speaker steps in Deep Dive to address
right/left speakers on top case
Take Apart:
• Battery: Added alternate part numbers for battery screws
• Trackpad: Added alternate part number for trackpad kit; corrected image for T6 set screw
• Logic Board: Added stacked serial number image; added reminder to enter product serial
number in GSX before ordering replacement part
• Top Case: Added reminder to enter product serial number in GSX before ordering
replacement part
Additional Procedures
• Trackpad Grounding Strap: Added new procedure to check for or install grounding strap
from chassis ground to trackpad; this addresses jumpy cursor movement symptom
Views:
• Exploded Views: Added new notes about the need to refer to GSX for the most accurate
parts list; added second Main View for modied part numbers
• Screw Locations: Added alternate part numbers for battery screws
Updated 18 February 2010
Take Apart:
• General Information: Connector Types on Logic Board: Added LVDS cable image and
replacement caution to check for gold traces
• General Information: Tools: Added torque driver recommendation for 6 display screws
• Bottom Case: Added new Replacement step 4 to align bottom case notches to clutch
• Rear Vent: Added optional torque driver to Tools; revised step 2 screws, including new 4-mm
screw with red locktite and screw ID table; added torque specications
• Logic Board: Added optional headphone jack to Tools; added new Replacement steps 4-6 to
align ports using a headphone jack
• Display Module: Added optional torque driver to Tools; revised Replacement step 1 to
include torque specications
• Top Case with Keyboard: Added replacement note about transferring the trackpad
Views:
• Screw Locations: Added torque specications for 6 display screws
Updated 15 January 2010
Take Apart:
• Battery: Added battery label reminder
