MacBook (13-inch) Take Apart — Camera Assembly 247
Replacement Note: The camera assembly includes:
Camera bracket
Camera board
Camera in plastic case
Flex cable from camera case to camera board
Screws
Replacement Note: Be sure to reinstall the microphone in the gasket before securing the
2-mm long camera board screws.
Replacement Note: When reinstalling the USB line, no copper contacts should be visible.
Reinstall the cable if you can see copper contacts.
Wrong
Right
•
•
•
•
•
•
•
