MacBook (13-inch) Take Apart — Trackpad Cable (Late 2006 Model Only) 44
Note: The shape of the mylar shield may dier slightly. This one includes a squared-o tab:
Caution: The trackpad cable locking lever at the top of the connector is fragile. Use a black
stick to carefully tilt up the lever until it is vertical (as shown by the detailed image on right).
Replacement Note: When locking the trackpad cable lever, make sure it is completely
closed, as shown by the detailed image on left below.
5.
