Applied Wireless Inc.
Remote Control Transmitters
Models KTX24SS1, KTX24SS, KTX24SS3
KTXW24SS3, NTX24SS1, NTX24SS2
Remote Control Receivers
Models RCR24SS-3R
Product Descriptions
These remote control receivers and transmitters are designed to provide a
quick and cost effective solution for a variety of wireless remote control
applications. The receiver utilizes Spread Spectrum technology and offers
excellent electromagnetic interference (EMI) tolerance, often found AC
and DC motor applications. The receiver includes three low voltage,
internal, 10-Amp, SPDT relays and an external whip antenna. Expected
range with these products is 350 to 500 feet*. The range may be increased
through the use of a higher gain antenna (800253-5-RC) at the receiver.
These products will not interfere with or be affected by Wifi systems.
The receiver runs on 12 to 24 Volts AC or DC (supply not included).
Through the use of jumper settings on the receiver board, the receiver can
be operated in momentary, latched (one button on, one button off), or
toggle modes.
The receiver can quickly “learn” up to 60 Applied Wireless transmitters
with different address codes. All keyfob transmitters come from the
factory with a unique ID code. A receiver will only respond to the
transmitter whose ID code has been “learned”. All other transmissions
from transmitters with different ID codes will be ignored. Multiple
transmitters and receivers may be used in the same area without
interfering with each other.
Keyfob transmitters are available with 1, 2 or 3 buttons. Power for the
keyfob is supplied by a widely available 12V battery (included). An
indicator LED indicates the transmitter is transmitting.
* Unobstructed, straight line-of-sight range, when used with the standard antennas
included with the receiver.
Installation Instructions
Before Beginning the Installation
Plan your installation carefully. The physical location and orientation of the
receiver will have a significant influence on reception, particularly at longest
ranges. For best results, the receiver antenna, should be positioned
vertically (pointing either up or down). If necessary, use double-sided foam
tape or hook & loop fasteners (not supplied) to secure the transmitter to a non-
metallic vertical surface. Also, keep in mind that the RF signal from the
transmitter will travel through most non-metallic building materials (wood, stucco,
brick, etc.), however maximum stated reception range is based on unobstructed
line of sight conditions.
Keyfob Button/ Relay Assignment
The number of buttons on the KTX transmitter determines which relay in the
RCRC-3R receiver responds to each button, as illustrated below:
Transmitter
Type
Transmitter
Button Numbe
