TABLE C1 - HEADLAMP PRE-FITTING
•
Check if the connectors tongues are
well attached
TABLE C2 - HEADLAMP PRE-FITTING
•
Clamps position inserting them in the
connectors tongue, after connecting to
the headlamp
TABLE C3 - HEADLAMP PRE-FITTING
•
Check that the connectors are correctly inserted after placing and tightening the clamps
TUONO V4 R a-PRC ABS Electrical system
ELE SYS - 103
