１３
6.4 Slide the filter screen (NO.7) back onto dust cup and rotate it clockwise to fix. Refit the HEPA filter
(NO.6) back onto filter screen (Pay attention to the position arrow of NO.6 and NO.7). See Figure 6-9.
Engage the hook (NO.9) into the hole (NO.10), then slide the dust cup into the main unit.
See Figure 6-10.
Figure 6-10
7
1
0
9
6
Figure 6-9
