Attention: do not make the bead too tight
Hold the device in a suitable position, and press the up or
down button of the device to ensure that the bead chain
rotates in a stable manner and does not slip (press the up or
down button again to stop the motor while rotating).
4
Hold the device on the selected installation position, and
outline the shape of the device along its bottom on the wall
with a pencil.
5
Remove the back cover of the device and fix it at the position
about 3-5 mm down from the mark.
Use screws to fix the product. Aer fixing the back cover,
install the device together with the bead chain back on the
back cover.
6
Push the handle to
remove the back cover
5mm
4
