AQUACLEAR
®
POWER FILTERS FLOW RATES
MODEL # 20 30 50 70 110
Maximum Flow Rate 100 gph 150 gph 200 gph 300 gph 500 gph
378 lph 568 lph 757 lph 1135 lph 1890 lph
Minimum Flow Rate 33 gph 50 gph 66.6 gph 100 gph 166.6 gph
125 lph 190 lph 250 lph 380 lph 630 lph
Watts 6 Watts 6 Watts 6 Watts 6 Watts 14 Watts
RPM 3600 rpm 3600 rpm 3600 rpm 3600 rpm 3600 rpm
POWER FILTER MAINTENANCE
Always unplug the Aquaclear
®
Power Filter prior to cleaning. Remove cover, filter basket,
and discard water remaining in the filter case. Thoroughly rinse collected debris from the
case, impeller cover and impeller assembly in clear lukewarm water. The intake "U" tube and
extension tube can be cleaned with a filter stem brush to remove any buildup of deposits.
When all parts have been cleaned and thoroughly rinsed, reassemble filter and replace onto
aquarium.
(See Quick Start Guide 2, 3 and 4.)
Follow operating
instructions to restart and
prime Power Filter.
(See Power Filter Start-Up.)
Every three months, the
motor should be
thoroughly cleaned.
Remove cover, filter basket
and discard water
remaining in filter case.
Remove motor by twisting
a 1/4 -turn gently in the
direction of the arrow on
front. Ease motor down
slowly to prevent damage
to the filter and motor
guide.
Pull impeller out of impeller
well and rinse to remove
accumulated slime deposits.
A cotton swab or impeller
well brush (not supplied)
can be used to remove
more stubborn deposits.
Wet motor seal ring to
prevent damage before
placing into filter case.
