Rev A

OPERATING INSTRUCTIONS

MODEL DC4256 DIRECTIONAL COUPLER

CAUTION:

Do not obstruct air holes on sides. Physical location must be such that air

can flow through unit.

WARNING:

Do not excee

d maximum power ratings. Do not drop. Internal

components are fragile.

Refer to drawing 10030590 at the end of this section for dim

ensions and connector locations.

Operation of the Model DC4256 is quite simple. The input signal is fed into the jack (J1) marked INPUT and

the output is taken from the jack (J2) marked OUTPUT. The input and output jacks on the unit are Type

EIA, 1-5/8 inch Flanges.

Forward coupled output is taken from the jack (J3) marked FWD, and Reverse coupled output is taken from

the jack (J4) marked REV. Both coupled output jacks on the unit are Type N (Female).

See Specification Sheet for detailed specification.
