ARC 2000 Series - Page 2

Fine height adjustment—
note hex nut tightened to
lock against end of leg.
Hex nut
Thread retainers onto
pad (note reverse
threading).
Press plugs into
seat holes if
pad isn’t used.
2000 Series Shower Seat
ARC, Inc.
1-715-743-2771
info@arcrst.net
16
5
⁄
8
"
18"
13
1
⁄
4
"
11
1
⁄
2
"
14
1
⁄
2
"
38
3
⁄
8
"
to
40
1
⁄
4
"
19"
to
23
7
⁄
8
"
6
1
⁄
2
"
1
5
⁄
8
"
3
7
⁄
8
"
23
1
⁄
4
"
4"
Seat width overall: 18"
Seat depth overall: 15"
Wall to front edge of seat: 19
1
⁄
4
"
Seat pad dimensions: 16
1
⁄
4
" × 12
1
⁄
2
"
Seat pad item code: 02011
Back pad dimensions: 13
5
⁄
8
" × 9"
Back pad item code: 02212
