15
14
5 Grill
Soles and cuttlefish
Squid and prawn kebabs
Cod filet
Grilled vegetables
Veal steal
Cutlets
Hamburgers
Mackerels
Toasted sandwiches
1
1
1
1
1
1
1
1
-
3
3
3
3
3
3
3
3
3
5
5
5
5
5
5
5
5
5
Max
Max
Max
Max
Max
Max
Max
Max
Max
8-10
6-8
10
10-15
15-20
15-20
7-10
15-20
2-3
With rotisserie (where prevent)
Veal on the spit
Chicken on the spit
Lamb on the spit
1.0
1.5
1.0
-
-
-
5
5
5
Max
Max
Max
80-90
70-80
70-80
6 Fan Assisted
Grill
Grilled chicken
Cuttlefish
1.5
1.5
3
3
5
5
200
200
55-60
30-35
With rotisserie (where prevent)
Veal on the spit
Chicken on the spit
Chicken (on the spit)+potatoes
(roasted)
Lamb on the spit
1.5
2.0
1.5
-
1.5
-
-
-
2
-
5
5
5
5
5
200
200
200
200
200
70-80
70-80
70-75
70-75
70-80
7 Baking
Tarts
Fruit cakes
Fruitcake
Sponge cake
Stuffed pancakes) on 2
racks)
Small cakes (0n 2 rakes)
Cheese puffs (on2 cakes)
Cream puffs (on 3 cakes)
Biscuits (0n 3 racks)
Meringues (0n 3 racks)
0.5
1
0.7
0.5
1.2
0.6
0.4
0.7
0.7
0.5
3
2/3
3
3
2-3
2-3
2-3
1-4
1-4
1-4
15
15
15
15
15
15
15
15
15
15
180
180
180
160
200
190
210
180
180
90
20-30
40-45
40-50
25-30
30-35
20-25
15-20
20-25
20-25
180
8 Fast cooking
Frozen food
Pizza
Courgette and prawn pie
Country style spinach pie
Turnovers
Lasagne
Golden Rolls
Chicken morseis
0.3
0.4
0.5
0.3
0.5
0.4
0.4
2
2
2
2
2
2
2
-
-
-
-
-
-
-
250
200
220
200
200
180
220
12
20
30-35
25
35
25-30
15-20
Pre-cooked food
Golden chicken wings 0.4 2 - 200 20-25
Fresh Food
Biscuits(short pastry)
Fruitcake
Cheese puffs
0.3
0.6
0.2
2
2
2
-
-
-
200
180
210
15-18
45
10-12
9 Pizza
Pizza
Roast veal or beef
Chicken
0.5
1
1
3
2
2/3
15
10
10
220
220
180
15-20
25-30
60-70
NB: co
oking times are approximate and may vary according to personal taste .When cooking using the grill or fan
assisted grill the dripping pan must always be placed on the 1st oven rack from the bottom.
Installation
Only a qualified person in compliance with the instructions provided must install the appliance. Appliance
are fully assembled as in normal operation without any parts removed.The manufacturer declines all responsibility
for improper installation, which may harm persons and animals and damage property.
Important: - The power supply to the appliance must be cut off before any adjustments or maintenance work is
done on it;
- Air duct is supposed to use in Ventilation.
Installation of Built-in Ovens
In order to ensure that the built-in appliance functions properly, the cabinet containing it must be appropriate .The
figure below gives the dimensions of the cut-out for installation under the counter .
In order to ensure adequate ventilation ,the back panel of the cabinet unit must be removed .
The oven must have a 40mm clearance between the oven and the rear timber panel.
The panels of the adjacent cabinets must be made of heat-resi
stant material .In particular ,cabinets with a veneer
exterior must be assembled with glues which can withstand temperatures of up to 100℃.
In compliance with current safety standards, contact with the electrical parts of the oven must not be possible once
it has been installed.
The oven must be secured by 4 screws to the cabinet.
Electrical Connection
