Arctic 2789 - Specifications and Troubleshooting; Technical Data

Smittybilt, 400 West Artesia Blvd, Compton, CA 90220
Owner’s
Manual
(Part #2789)
Tech Data
SB
Overall capacity
52 QT/50L
Connection voltage North America
12/24V DC and 100-240V AC
50/60Hz
Rated current
-12 VDC (35°F inside, 68°F outside)
Approximately 0.7AH/h
-100-240 VAC
6 amps
Average power consumption
40 Watts
Cooling capacity
-30°C TO 10°C(-22°F TO 50°F)
Weight
40.8 lbs.
External dimensions (HxWxD)
520mm x 335mm x 682mm
20.47" x 13.19" x 26.85"
Max operating angle
30°
Certification
GS,CE,E certified
Minimum clearance
4"
Battery protection
3 Stage low voltage protection
Coolant
R-134a (50g)
Interior and exterior dimensions
International Certification Approvals
SAA
