SETTINGS
Delay start time setting
Time delay start time can be set as shown in figure by the time delay dial switch SW1. 1, 2 to set
the ARD start time after power outage. 3, 4 is to set the ARD rescue to complete the signal down
time.
Switch set parameter table
VR1 = output voltage adjustment
VR2 = over load adjustment
Start
delay
time
Switch position Close
delay
time
Switch position
1 2 3 4
5 seconds OFF OFF 0second OFF OFF
10 seconds OFF ON 10seconds OFF ON
15 seconds ON OFF 15seconds ON OFF
30 seconds ON ON 30seconds ON ON
