ARDES AR5EA41 - Product Assembly Guide; Fan Operation Instructions; Oscillation Control; Vertical Angle Adjustment

11
ASSEMBLING
1. Base
2. Main body
3. Control panel
4. Motor shaft
5. Oscillation knob
6. Safety screw
7. Front grille
8. Lock ring of the fan
9. Fan
10. Lock ring of the back grille
11. Back grille
12. Motor
A-B. Locking pin for the rear grille
INSTRUCTIONS FOR USE
Place the fan on a at, dry and stable surface, and insert the plug of the
fan in a socket. Select the desired speed by rotating the knob on the
control panel (3):
0 = o󰀨 1 = minimum speed 2 = medium speed 3 = maximum speed
OSCILLATION:
For the automatic oscillation from right to left press the knob (5) placed
on top of the motor. To disable it, pull up the knob.
VERTICAL SLOPE:
You can vertically point the front of the fan
choosing the desired angle. It is su󰀩cient to
move the front of the fan up or down according
to the desired slope.
(see image at last page)
