This document provides instructions for the Ardes ZAK Art.606, a suction-type mosquito net.

Function Description

The Ardes ZAK Art.606 is an ecological mosquito net designed to attract and capture flying insects, primarily mosquitoes, using a special actinic light source and a turbo aspiration system. The actinic lamp (2) attracts insects, which are then drawn into a removable drawer (4) by an axial-radial profile propeller that enhances the attraction force. Once in the drawer, the insects cannot escape. The device is intended for internal use only and provides efficient insect control, especially when kept running continuously, even during the night.

Important Technical Specifications

Model: Ardes ZAK Art.606
Type: Suction Type Mosquito Net
Actinic Lamp: 20 W
Radius of Action: 110 m²
Components:
- Hook (1)
- Actinic lamp (2)
- Switch (3)
- Removable collector (4)
Compliance: Designed in accordance with current directives 2006/95/EC and 2004/108/EC.
Power: Technical data is specified on the appliance's label.

Usage Features

Installation and Setup:

Mounting the Hook: Insert the supplied hook (1) into position on the top of the appliance and rotate it a quarter turn until it stops. Pull upwards to ensure it is securely attached.
Power Connection: Plug the power cord into a suitable power outlet. Ensure the voltage in the socket matches the appliance's nameplate data. If the plug and socket are incompatible, have the socket replaced by a qualified professional. Avoid using adapters or extension cords that do not comply with safety standards or exceed current flow limits.
Operation: Turn on the appliance using the switch (3).

Placement Recommendations:

Place the appliance on a flat, stable surface.
Position the appliance at least 2 meters away from people to prevent disturbance from insects before they are captured.
Avoid directing the lamp towards doors, windows, or other external openings to prevent attracting unwanted insects from outside.
The appliance is intended for internal use only; do not use it outdoors.
Do not use the appliance inside barns, stables, or similar environments.
Do not use in environments where flammable fumes or explosive powders may be present.

Safety Instructions:

Read the instructions carefully for safe installation, use, and maintenance.
This appliance can be used by children aged 8 years and above, and by persons with reduced physical, sensory, or mental capabilities, or lack of experience/knowledge, provided they are supervised or have received instructions on safe use and understand the risks.
Children should not play with the appliance.
Cleaning and maintenance should not be performed by unsupervised children.
Keep packaging out of reach of children.
Do not touch the appliance with wet or damp hands.
Do not use the appliance with bare feet.
Do not expose the appliance to atmospheric agents (rain, sun).
Do not subject the appliance to shocks.
Disconnect the appliance from the mains when not in use and ensure it is turned off.
Do not pull the power cord or the appliance itself to remove the plug from the socket.
If there is a fault or abnormality, immediately unplug the device, do not touch it, and contact an authorized service center.
If the appliance is no longer to be used, render it inoperative by cutting the power cord after disconnecting it from the outlet.
For safety reasons, the appliance cannot be disassembled by the user.
Use only original accessories to maintain functionality.

Maintenance Features

General Maintenance:

Always disconnect the plug from the power socket before performing any cleaning or maintenance.
Clean the product with a soft, damp cloth.
Do not use any substances, liquids, or excessively wet cloths, as infiltration into the appliance could cause irreparable damage.
NEVER IMMERSE THE APPLIANCE IN WATER.

Collector Cleaning (Removable Collector 4):

Preparation: Before emptying the drawer, turn off the appliance for a few hours to ensure any captured insects are no longer alive and cannot escape.
Removal: Rotate the insect collector (4) in the direction of the arrow and pull it out.
Emptying: Turn the cover of the collector as indicated on the cover itself to open it. Empty the collected insects.
Reassembly: After emptying, reassemble the collector in reverse order. Match the arrow on the bottom of the collector with one of the arrows marked on the bottom of the appliance for correct repositioning.

Lamp Replacement:

It is advisable to replace the actinic lamp (2) every 12 to 18 months to maintain the appliance's efficiency.
The lamp may only be replaced at service centers authorized by the manufacturer with a product of the same specifications.

Power Cord Replacement:

If the power cord is damaged, it may only be replaced at service centers authorized by the manufacturer.

ARDES ZAK - Technical Information and Components; Appliance Components Identification; Design Compliance and Specifications
