A&E Specification AV5585PM Rev. 061616

425 E. Colorado Street, 7

Floor (818) 937-0700 Page 4

Glendale, CA 91205 www.arecontvision.com

2.7 Electrical

 General purpose opto-coupled 1 input and 1 output

 Power over Ethernet (PoE): PoE 802.3af, Class 3

 Auxiliary Power 18-48V DC, 24VAC

 Power consumption: PoE – Class 3;

 10 Watts (Max Auxiliary DC Power) PoE Class 3

2.8 Heater Electrical

 External Power Consumption 11 W Max

 Switch On: 17°C (62.6°F), Off: 30°C (86°F)

 Voltage Input: 12V to 35V DC, 24 VAC (separate power required)

 Power Consumption of 11 Watts (Max DC Power) / 13 Watts (Max AC Power)

2.9 Networking

 The camera shall be equipped with a 100 Mbps LAN connector.

2.10 Environmental

 Operating temperature -40˚C (-40 °F) to +50˚C (122 °F)

 Stable image temperature 0˚C (32 °F) to +50˚C (122 °F)

 Motorized lens operating temperature -20˚C (-4°F) to +50˚C (122 °F) w/ heater

 Storage temperature -40˚C (-40 °F) to +60˚C (140 °F)

 Humidity 0% to 90% (non-condensing)

2.11 Illumination

Color (Day Mode): 0.02 Lux

B/W (Night Mode): 0.002 Lux

2.12 Packaging

Unit Dimensions (H x Dia) 6.55”H (166 mm) x 6.9” dia. (175 mm) Weight: 3.54 lbs (1.6 kg)

Packaged Dimensions (H x W x L) 8.5” (215mm) x 8.5” (215mm) x 8.5” (215mm) Weight: 4.37 lbs (1.98 kg)

2.13 Compatible Accessories

AV-CRMA – Corner Mount Adapter

AV-JBA – Junction Box Adapter

AV-PMA – Pole Mount Adapter

AV-PMJB – Pendant Mount Bracket with Junction Box

AV-WMJB – Wall Mount Bracket with Junction Box

SV-CAP – Wall Mount Cap Only

AV-EBA – Electrical Box Adapter

SV-FMA - Flush Mount Adapter

2.14 Related Documents

SurroundVideo® G5 Datasheet

SurroundVideo® G5 Installation Manual

Arecont Vision AV5585PM User Manual
