10. After installing the conversion kit, verify that the components are still correctly positioned
(see diagram below).
NOTE: Igniter housing removed for example only.
Igniter Pin
You should see the
igniter pin spark
when pushing the
igniter button.
Thermocouple
Make sure the flame
is contacting the
thermocouple.
CONVERSION INSTRUCTIONS
!
If the table is installed with a portion of the
hose under the table, the hose must be
secured, so that no part of the hose will be
within 1” or come in contact with the
underside of the burn pan or where the hose
will not be accidentally damaged or pinched.
Failure to secure the hose in a safe location
may result in a gas leak that could cause
property damage, injury, or death. Follow
all other hose inspection instructions
listed in this manual.
WARNING
Coil near a corner that is
adjacent from the valve.
Valve
Do not coil the hose
beneath the valve.
1”
The hose should not come within 1”
from the bottom of the burn pan.
Emergency
shut-off valve
