Ariston ARWDF 129 - Washer-Dryer Description; Control Panel Overview

7
NA
WARNING: To reduce the risk of fire, electric shock, or
injury to persons, read the IMPORTANT SAFETY IN-
STRUCTIONS before operating this appliance.
Detergent dispenser drawer: used to dispense
detergents and washing additives (see “Detergents and
laundry”).
ON/OFF button with indicator light: switches the machine
on and off.
If the indicator light is illuminated, this indicates that the
machine is switched on.
WASH CYCLE knob: programmes the wash cycles. During
the wash cycle, the knob does not move.
DRYING button: used to set the desired drying program-
me (see “Personalisation”).
TEMPERATURE button: sets the temperature or the cold
wash cycle (see “Personalisation”).
The wash temperatures selections are uniformly distribuited.
DISPLAY: indicates the time remaining for the selected
washing/drying cycle and, if a delayed start has been
programmed, the time remaining until the start of the wash
cycle.
CHILD LOCK button with indicator light: activates or
deactivates the control panel lock.
FUNCTION buttons with indicator light: used to select the
available functions. The indicator light corresponding to the
selected function will remain lit.
WASH CYCLE PROGRESS indicator light s: used to
monitor the progress of the wash cycle.
The illuminated indicator light shows which phase is in
progress.
DOOR LOCKED indicator light: indicates whether the
door may be opened or not (see next page).
START/PAUSE button with indicator light: starts or tem-
porarily interrupts the wash cycles.
N.B. To pause the wash cycle in progress, press this
button; the corresponding indicator light will flash orange,
while the indicator light for the current wash cycle phase
willremainlitinafixedmanner.IftheDOORLOCKED
indicator light is switched off, the door may be opened.
To start the wash cycle from the point at which it was inter-
rupted, press this button again.
Description of the washer-dryer
and starting a wash cycle
DOOR
LOCKED
indicator light
START/PAUSE
button with indicator
light
Control panel
WASH CYCLE PROGRESS
indicator lights
FUNCTION
buttons with
indicator lights
Detergent dispenser drawer
WASH CYCLE knob
DISPLAY
ON/OFF
button with indicator
light
TEMPERATURE
button
DRYING
button
CHILD LOCK
button with indicator light
