Preventive Maintenance Schedule24
ADDITIONNAL POINTS TO BE INSPECTED BY
6(59,&(7(&+1,&,$1
FREQUENCY
Annually (12 Hours*)
Before every use
Initially ÐÐÐ
13) Make sure the shoulder bolt between the boom and the mast is securely fastened and that the
cotter pin is present.
x
14) Inspect all weld sites for cracking or separation. x
15) 0DNHVXUHWKDWDOOQXWVDQGORFNQXWVRIWKHEDVHRSHQ௘௘FORVHPHFKDQLVPDUHVHFXUHO\IDVWHQHG
and the ball joints are in good condition.
x
16) Check all bolts, nuts and locknuts to ensure they are tight. x
17) Check if the leg pivot bolts are secured with locknuts; tighten, if necessary. x
18) Make sure that the straight section of both legs is perpendicular to the base, in closed position. x
19) If the product does not work as intended, immediately contact your local Arjo vendor for support. x
20) &KHFNWKDWWKH6SUHDGHU%DUÀDQJHEXVKLQJVSLYRWEROWDQGZHOGVDUHLQJRRGFRQGLWLRQ x
21) Check the condition of the friction discs and bushings of the DPS within the pivot points.
If found worn and/or damaged, parts must be replaced.
x
22) When the friction discs and bushings of the DPS have been checked/replaced, reset friction
assembly to support a 5.4 kg (12 lb) load at the handle.
x
* Time period indicated by the Hour meter.
