7HFKQLFDO6SHFL¿FDWLRQV 27
PRODUCT INFORMATION MAXI 500 .0;;;;
Total weight (without battery or
accessory)
46,4 kg (102 lb)
Battery pack weight 5 kg (11 lb)
Lifting capacity 227 kg (500 lb)
Minimum door requirement 700 mm (27.5 in)
MECHANICAL
IP rating control lift
Lift: Refer IP24
+DQG&RQWURO,3;
Operating forces of controls
Hand Control: < 5 N
Sound power level
< 65 dBA
ELECTRICAL
Battery Type
Rechargeable (Sealed Lead-Acid)
Battery Capacity
24V, 4Ah
Battery charger input
1'$WR9DF௘௘+]௘௘9$
Battery charger output
24 Vdc, 1A, 24VA
Protection class
Class II, double insulated
8SDQGGRZQFXUUHQWOLPLWLQJ
10 A
Duty cycle
10%, 6 min / hour, 1 min continuous
Protection against electrical shock
Refer to product label
The Maxi 500 meets the requirements of Electromagnetic Compatibility (EMC)
DVVWDWHGLQFODXVHRIWKH0HGLFDO'HYLFHV'LUHFWLYH௘௘௘௘((&
The Maxi 500 is compliant to IEC 60601-1 series including applicable collateral standards and national
deviations. The Maxi 500 is compliant to ISO 10535 standard.
WARNING: Portable RF communications equipment (including peripherals such as antenna cables and external
antennas) should be used no closer than 30 cm to any part of the Maxi 500LQFOXGLQJFDEOHVVSHFL¿HGE\WKH
manufacturer. Otherwise, performance degradation of this equipment could result. See “Electromagnetic
Compatibility” section for more details.
(19,5210(17$/&21',7,216
Ground Requirement
Maximum Slope: 1°
Surface condition: Flat hard surface
Ambient temperature range (lift,
batteries)
Operation: 5° to 40°C (+41 to +104 F)
Storage: - 25 to 70°C (-13 to 158F)
Relative humidity range
Operation: 15 to 93%, non-condensing
Storage: < 93%, non-condensing
Atmospheric pressure range
Operation: 795 hPa to 1060 hPa (2000 m max)
Storage: 500 hPa to 1060 hPa
WARNING3URGXFWLVQRWVXLWDEOHLQWKHSUHVHQFHRIÀDPPDEOH
anaesthetic mixture with air or oxygen, or with nitrous oxide.
SAFE DISPOSAL at END of LIFE
Battery
All batteries in the product must be recycled separately. Batteries are to be
disposed in accordance with national or local regulations. Sealed lead-acid,
rechargeable, recyclable.
Package Wood and corrugated cardboard, recyclable.
Product
Components that are primarily be made up of different kinds of metal
(containing more than 90% metal by weight) for example sling bars, rails,
upright supports, etc., should be recycled as metals.
Electrical and electronic
components
Lift systems having electrical & electronic components or an electrical cord
should be disassembled & recycled per Waste of Electrical and Electronic
Equipment (WEEE) or in accordance with local or national regulation.
Slings
Slings including stiffeners/stabilisers, padding material, any other textiles or
polymers or plastic materials etc. should be sorted as combustible waste.
