Arlec WLED2030 User Manual

Important Notes
• Donotremovethesupportbracketfrom
thelampbody.
• Donotpinchorsharplybendthesupply
cordwhileadjustingthelamphead.
• Donotopentheworklightbody,thereare
nouserserviceablepartsinside.
• Donotimmerseinwaterorany
otherliquid.
• Donotuseabrasivecleaners,
cleanwithadampcloth.
• Ifthesuppliedexiblecordisdamaged
itmustonlybereplacedbyaservice
agentorsimilarlyqualiedpersoninorder
toavoidahazard.
High Output LED
Module Array
• 20WLEDarray
• Provideshighintensityeven
lightdistribution
• Indoor/Outdoorlightingforcontractor,
tradesman,andDIYapplications
• Cooltotouchdurablepolycarbonate/
aluminiumhousing
• Wideanglecoverageforlarge
workareas
• WeatherproofIP44rating.
Specifications
INPUT VOLTAGE
220-240Vac50Hz
WATTAGE
20W
IP CLASSIFICATION
IP44
LED
Superbrightmodule
•300mA
•29-35V
•20W
•6500K
(non-replaceabletype)
PROTECTIVE
SHIELD
GlassLens
172x110x3.85mm
thick
ENCLOSURE
polycarbonate/
aluminiumhousing
Holdstandhandlermly
Pushlamp
headforward
orbackwardto
desiredangle
70°
even
light
beam
WLED2030 A5_ 4 pAgE instruction mAnuAL cpin002943/2
Base
stand
Opening
adjacentto
theSupport
Bracket
opening
Fixing
knob
Introduction
TheArlecWLED2030issuitablefor
indoorandtemporaryoutdooruse.Itis
idealforcontractor,tradesmanandDIY
handymanapplications.Pleasenotethat
whenusedoutdoorsthesupplyplugand
socket-outletmustbesuitablyprotected
againstwateringress.
Assembly
Assembletheworklightasshownbelow.
1Removethexingknobwithintegralscrew
fromthebasestand,thenslidethebase
standintotheopeningadjacenttothe
supportbracket.
2Insertxingknobwithintegralscrewinto
thecaptivenutinsidebasestand,then
tightenrmly.
Tosetthetiltofthelampheadsimplyloosen
thexingknob,pushtheheadforward
orbackwardtothedesiredpositionwhile
holdingthebasestand,thentightenthexing
knob.
Note:Donotremovethesupportbracketfrom
thelampbody.Whileadjustingthelamphead
avoidpinchingorbendingofthesupplycord.
Use of Worklight
1 Adjustthetiltofthelampheadbypushing
thetopofheadforwardorbackwardtothe
desiredpositionwhileholdingthestand
rmlybythehandle.
2 Plugtheworklightintoapowerpoint.
3 Turnonthepowertotheworklight.
PORTABLE WORKLIGHT
20W
PORTABLE WORKLIGHT
20W
