Armada Avenger - Page 3

INSTRUCTIONAL MANUAL
3 | P a g e
2
7
9
10
12
13
14
16
18
17
15
1. On/Off key ignition
2. Battery charger port
3. Battery indicator (display
gage)
4. Forward/Reverse lever
5. Three speed switch
6. Rt. brake lever (Front brake)
7. Lf. brake lever (Rear brake)
8. Rt/Lt turn signal switch
9. Digital speedometer display
10. Throttle
11. Horn
12. Ft Lf. Turn signal light
13. Ft Rt. Turn signal light
14. Back Turn signal light
15. Seat
16. Peddles
17. Kickstand
18. Middle kickstand
19. On/off Front Headlight switch
20. High beam/low beam
1
3
4
6
8
11
11
5
7
10
19
20
