Assembly InstructionsStorage Cube
12
Part 1: Main Cabinet
F2
F3
d2
d1
d1
8x30 Dowel Pin x8
d1
6x50 Dowel Pin x18
d2
Insert d1 Dowel Pins into the edge of
Panel F2.
Insert d1 Dowel Pins into the edges of Panel F3.
Insert d2 Dowel Pins into the predrilled holes on Panel F3.
TIP: Glue will hold dowels securely in place. If you wish to reconfigure dowel placement in the future, do not use glue.
