Arrow 81100 - Completing Cabinet Structure; Attaching the Bottom Panel G

Assembly InstructionsStorage Cube
16
Part 1: Main Cabinet
G
O
O1
X
Z
5
⁄
8
“ Cam Cover x8
c2
Attach Panel G, lowering on to Panels Z,
X, O and O1 as illustrated.
Tighten all cam locks and apply c2 Cam
Covers.
Turn the cabinet over onto its wheels.
