Arrow 81100 - Page 19

Assembly InstructionsStorage Cube
19
O
O1
p
p
s2
Part 1: Main Cabinet
Plastic Support x4
p
3.5x12 Screw x4
s2
Using s2 Screws, attach p Plastic Support pieces
to the inside edges of Panels O and O1.
p
Nestle the Metal Bars into the p Plastic
Support pieces as shown above.
Metal Bar x2
