Step 4
1 Position short attic channels be-
tween long channels as shown. De-
pending on width of the wall panel on
your building, follow one of three pro-
cedures below, fastening channels
with four bolts and nuts.
LONG ATTIC CHANNEL ASSEMBLY
2 DIAGONAL PROCEDURES
STRAIGHT PROCEDURE
SHORT ATTIC CHANNEL 8227
