Assembly InstructionsOLIVIA Sewing Cabinet Page 5
Step 4. Insert 6x30mm Wood Dowels (x8) into each
Straight Gingerbread Piece (J) and 6x30mm Wood
Dowels (x4) into each Cabinet Side Connector (K)
(See FIG 4A). With the smooth edge facing the legs
on Panels (C, M), guide Connector Piece (K) into
Step 5. With Cams facing the legs of Panels (C,
M), attach Bottom Panel (E) to Panels (C, M), guide
FIG. 4A.
FIG. 4.
the Connecting Bolts Into the holes on the edge of
Panel (E) (As shown in FIG. 5). Tighten Cams (x4).
FIG. 5.
Panels (C, M). With the curved edge facing the legs on
Panels (C, M), guide Straight Gingerbread Piece (J) into
Panels (C, M) (As shown in FIG. 4).
Note: For added support, drop 2 to 3 drop of wood
glue in each dowel hole before inserting wood dowels.
Allow several minutes to dry.
Wood dowel 6x30mm x12
x2
x2
