artemis сomponents manual
Side Тo
Side
lnputs
and
Outputs
12Vl24V Cаmera Power
out
Тhese
sockets aIways
supp|y
12 vdс
сamera
power.
After
se|eсting
24Yo||
these
soсkets
provide
eхtra 24vсd сamerа
power.
Тhese
soсkets
сan
power
aссessories
(сamera
on board |ight,....) with max.
3
Amps /
25 Watts.
ln 12 Vo|t mode,
these
soсkets are
powered
by the
Camera.Battery,
in 24 VoIt mode
by the
Camera-Batt and the MoilCam-Battery.
Foсus Power
out / Tally Signal ln
These
soсkets
provide
two
funоtions:
Focus Power Out:
Suppy|ing various remote foсus
сontro|s
(Genio,
Fox,eоt.) with 12
VDC.
The
Cаmera
вattery
powers
these
outputs.
Tаlly Signalln:
Тhe
seсond funсtion is
to serve as inputs for the internal
tally
system. Тhe ta|ly
signa|
сab|e is
p|ugged
in here.
For this reason
there are two
soсkets at the front of the
side to side module.
When
one
soсket
is
oсcupied by the remote foсus
сontrol,
the seсond
soсket
is
used
for the
ta||y signa| сab|e.
Тa||y
Sensor
Cable
Video / Power Out
At this
output
video
transmitters
are
plugged
in. Тhis output
provides
12 vDс and the
сamera
video
signal. ln 12V mode
the
Mon/Cam-Battery
powers
this output, in24Y mode the C-Battery.
Aux Power
out/Tа|ly out
Тhis
soсket also
provides
two funсtions:
12V AuxPower
Out
Тhe
first
funсtion is
to supp|y
various
acсessories
(audio
transmitter, timecode
generators,
...) with
12 VDс.
These
outputs
powered
by
the
Camera Battery
must
not
be used for
deviсes сonsuming high сurrents
(max
1.5 Amps).
TаIly
out
Seсond funсtion is to
provide
the
red |ight
(tally).
Here
you
сan
p|ug
in
the upper tally red light.
Upper
Тa||y Light
Video ln
Тhe
different
video-in
cab|es are
p|ugged
in
here. There are
two ditferent
video.in сab|es:
blaсk сab|es for ana|og app|iсations
(standard
video
and
film
сameras) and the
three-сored
RGB
сab|e
for HD
сameras.
