Gree GMV6 DC Inverter VRF Units Service Manual
3
2 Parameters
2.1 Parameters of Basic Modules
Model - GMV-224WM/H-X GMV-280WM/H-X GMV-335WM/H-X GMV-400WM/H-X
HP HP 8 10 12 14
Product Code
-
CN851W3040
CN851W2900
CN851W2910
CN851W3050
Cooling capacity Rated kW 22.4 28 33.5 40
Heating capacity
Rated kW 16.2 16.2 18.5 23.32
Max. kW 25 31.5 37.5 45
Outdoor static pressure Pa 0-110 0-110 0-110 0-110
Sound pressure level(Cooling) dB(A) 56 57 59 59
Sound power
level(Cooling)
dB(A) dB(A) 81 83 88 85
dB(A) dB(A) 81 86 88 88
Power Supply -
380-415V 3N~
50/60Hz
380-415V 3N~
50/60Hz
380-415V 3N~
50/60Hz
380-415V 3N~
50/60Hz
Rated power input kW 12.87 13.15 13.50 21.0
Rated current A 23.0 23.5 24.1 37.5
Compressor type - Inverter scroll Inverter scroll Inverter scroll Inverter scroll
Compressor quantity N 1 1 1 1
Refrigeration oil No. of compressor - FV68H FV68H FV68H FV68H
Refrigeration oil charge
Gross L 4.6 4.6 4.6 6.1
Compressor
charge
L 1.1 1.1 1.1 1.1
The others L 3.5 3.5 3.5 5
Cooling operation range °C -5~55 -5~55 -5~55 -5~55
Heating operation range °C -30~24 -30~24 -30~24 -30~24
Refrigerant type - R410A R410A R410A R410A
Refrigerant charge kg 5.5 5.5 7.5 7.5
Maximum drive IDU NO. unit 13 16 19 23
Gas pipe mm Φ19.05 Φ22.2 Φ25.4 Φ25.4
Liquid pipe mm Φ9.52 Φ9.52 Φ12.7 Φ12.7
Outline dimensions(W × D × H) mm 930×775×1690 930×775×1690 930×775×1690 1340×775×1690
Packing dimensions (W × D × H) mm 1000×830×1855 1000×830×1855 1000×830×1855 1400×830×1855
Net weight kg 220 220 240 300
Gross weight kg 230 230 250 315
Model - GMV-450WM/H-X GMV-504WM/H-X GMV-560WM/H-X GMV-615WM/H-X
HP HP 16 18 20 22
Product Code - CN851W2930 CN851W3060 CN851W3070 CN851W2940
Cooling capacity Rated kW 45.00 50.40 56.00 61.50
Heating capacity
Rated kW 23.32 31.00 31.00 33.00
Max. kW 50.00 56.50 63.00 69.00
Outdoor static pressure Pa 0-110 0-110 0-110 0-110
Sound pressure level(Cooling) dB(A) 60 61 62 63
Sound power
level(Cooling)
dB(A) dB(A) 89 93 93 93
dB(A) dB(A) 93 88 94 94
Power Supply -
380-415V 3N~
50/60Hz
380-415V 3N~
50/60Hz
380-415V 3N~
50/60Hz
380-415V 3N~
50/60Hz
Rated power input kW 22 26.3 26.85 27.41
Rated current A 39.3 47 48 49
Compressor type - Inverter scroll Inverter scroll Inverter scroll Inverter scroll
