Gree GMV6 DC Inverter VRF Units Service Manual
52
LED1
LED2
LED3
Function code
Display status
Mode
Display status
Current status
Display status
1G
On
ADD
On
02
Blinks
1G
On
ADD
On
03
Blinks
1G On ADD On 04 Blinks
After selecting the corresponding static pressure mode for the outdoor unit, press the SW3 confirm
button. The master module displays as follows:
LED1
LED2
LED3
Function code Display status Mode Display status Current status Display status
1G
On
ADD
On
00
On
1G
On
ADD
On
01
On
1G
On
ADD
On
02
On
1G
On
ADD
On
03
On
1G
On
ADD
On
04
On
Each basic module memorizes this setting and does not clear it even upon power failure and
power-on again. The default value is 00.
4.2.3.10 qJ One-button Drainage
Code
Meaning
on
One-button drainage
OF
Non-one-button drainage
Setting steps:
Enter the function setting. The master unit displays as follows by default:
LED1 LED2 LED3
Function code Display status Current module Display status
One-button
drainage code
Display status
qJ On OF Blinks 00 Blinks
Press the SW3 confirm button. The master unit displays as follows:
LED1 LED2 LED3
Function code Display status Current module Display status
One-button
drainage code
Display status
qJ On OF Blinks 00 Blinks
Press the SW1 up button and the SW2 down button to select the corresponding status, and press
the SW3 confirm button.
LED1 LED2 LED3
Function code Display status Current module Display status
One-button
drainage code
Display status
qJ On on or OF On oC On
After the setting is completed, if you do not press any button in 10s, the system will automatically
exit the current screen and resume displaying the current standby status.
Note:
The one-button drainage function is valid in running or standby status of the entire system. After
entering the one-button drainage function, the outdoor unit sends a forced shutdown instruction, and the
indoor unit shuts down. When the system exits drainage, the forced shutdown instruction is canceled. If
