Gree GMV6 DC Inverter VRF Units Service Manual
5
Model
-
GMV-950WM/H-X
GMV-1015WM/H-X
GMV-1065WM/H-X
GMV-1119WM/H-X
HP
HP
34
36
38
40
Combination
mode
- 12+22 14+22 16+22 18+22
-
GMV-335WM/H-X+
GMV-615WM/H-X
GMV-400WM/H-X+
GMV-615WM/H-X
GMV-450WM/H-X+
GMV-615WM/H-X
GMV-504WM/H-X+
GMV-615WM/H-X
Cooling
capacity
Rated kW 95 101.5 106.5 111.9
Heating
capacity
Rated
kW
51.5
56.32
56.32
64
Max.
kW
106.5
114
119
125.5
Outdoor static
pressure
Pa 0-110 0-110 0-110 0-110
Power Supply - 380-415V 3N~ 50/60Hz 380-415V 3N~ 50/60Hz 380-415V 3N~ 50/60Hz 380-415V 3N~ 50/60Hz
Rated power input kW 13.5+27.41 21+27.41 22+27.41 26.3+27.41
Rated current
A
24.1+49
37.5+49
39.3+49
47+49
Cooling operation
range
°C -5~55 -5~55 -5~55 -5~55
Heating operation
range
°C -30~24 -30~24 -30~24 -30~24
Refrigerant type
-
R410A
R410A
R410A
R410A
Refrigerant charge kg 15.8 15.8 15.8 16.6
Maximum drive
IDU NO.
unit 56 59 63 64
Gas pipe
mm
Φ31.8
Φ38.1
Φ38.1
Φ38.1
Liquid pipe
mm
Φ19.05
Φ19.05
Φ19.05
Φ19.05
Outline
dimensions
(W × D × H)
mm
930×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690
Packing
dimensions
(W × D × H)
mm
1000×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855
Net weight
kg
595
655
655
705
Gross weight
kg
620
685
685
735
Model - GMV-1175WM/H-X GMV-1230WM/H-X GMV-1290WM/H-X GMV-1345WM/H-X
HP
HP
42
44
46
48
Combination
mode
-
20+22
22+22
10+16+20
10+16+22
-
GMV-560WM/H-X+
GMV-615WM/H-X
GMV-615WM/H-X+
GMV-615WM/H-X
GMV-280WM/H-X+
GMV-450WM/H-X+
GMV-560WM/H-X
GMV-280WM/H-X+
GMV-450WM/H-X+
GMV-615WM/H-X
Cooling
capacity
Rated kW 117.5 123 129 134.5
Heating
capacity
Rated
kW
64
66
70.52
72.52
Max.
kW
132
138
144.5
150.5
Outdoor static
pressure
Pa 0-110 0-110 0-110 0-110
Power Supply - 380-415V 3N~ 50/60Hz 380-415V 3N~ 50/60Hz 380-415V 3N~ 50/60Hz 380-415V 3N~ 50/60Hz
Rated power input
kW
26.85+27.41
27.41+27.41
13.15+22.00+26.85
13.15+22.00+27.41
Rated current
A
48+49
49+49
23.5+39.3+48
23.5+39.3+49
Cooling operation
range
°C -5~55 -5~55 -5~55 -5~55
Heating operation
range
°C -30~24 -30~24 -30~24 -30~24
Refrigerant type
-
R410A
R410A
R410A
R410A
Refrigerant charge
kg
16.6
16.6
21.3
21.3
Maximum drive
IDU NO.
unit 64 64 64 64
Gas pipe mm Φ38.1 Φ38.1 Φ38.1 Φ41.3
Liquid pipe
mm
Φ19.05
Φ19.05
Φ19.05
Φ19.05
Outline
dimensions
(W × D × H)
mm
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690
930×775×1690+
1340×775×1690+
1340×775×1690
930×775×1690+
1340×775×1690+
1340×775×1690
Packing
dimensions
(W × D × H)
mm
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855
1000×830×1855+
1400×830×1855+
1400×830×1855
1000×830×1855+
1400×830×1855+
1400×830×1855
Net weight kg 705 710 870 875
Gross weight
kg
735
740
910
915
