34
Icons table
Main universal input Digital input
Thermocouple Isolated contact
RTD (Pt100) NPN open collector
Delta Temp (2x RTD) TTL open collector
mA and mV
Setpoint
Custom Local
Frequency Stand-by
Auxiliary input
Keypad lock
Current transformer Outputs lock
mA Remote setpoint Start-up function
Volt Remote setpoint Timer function
Feedback
potentiometer
Memorized
Remote
Setpoint programmer
Logic
mA mV
mA
SPDT Relay
Triac
SPST Relay
Output
Setpoint slopes
inhibition
PV hold
Run, Hold, Reset and
program selection
Auto/Manual
Digital input
connected functions
ICONS TABLE
J1 EN-ed3 17-02-2009 15:05 Pagina 34
