1. Main switch (ON/OFF)
2. Program selector knob
3. Display unit
4. Program settings buttons
5. Button (start/pause)
6. Detergent compartment
7. QR and AUID code (on the inside of the washing
machine door)
8. Rating plate with information about the washing
machine (on the inside of the washing machine
door)
9. Washing machine door
10. Drain fi lter cover
11. Water release hose
12. Drain fi lter pump (installed behind the drain
pump fi lter)
WASHING MACHINE DESCRIPTION
DETERGENT COMPARTMENT
15
910
267834
1211
1
4
5
3
2
1. Prewash compartment
2. Compartment for main wash liquid
detergent.
Use the foldable barrier (3).
2. Compartment for main wash powder
detergent.
Do not use the foldable barrier (3).
4. Softener / conditioner compartment
5. Tab for detergent compartment removal
