Asko WM75.1 - Page 41

41
PERFORMANCE DATA
Program Maximum load Temp. °C
Standard cotton + ECO
1)
8 / 9 kg (depending
on model)
60 °C 40 °C
Mix/Synthetics
2)
3,5 kg 40
1)
Test program for connection to cold water supply, pursuant to EN 60456.
2)
40 °C program for testing institutes. The 40 °C option has to be set.
ENERGY LABELLING
European test standard EN 60456
Washing program Standard cotton + ECO
60 °C 40 °C
, 8 / 9 kg cotton
(depending on model)
Connection Cold water 15 °C
Noise testing method IEC-60704-2-4
TECHNICAL INFORMATION
Height 850 mm
Width 595 mm
Depth 580 mm
Weight 75 / 76 kg (depending on model)
Drum volume 60 l
Rated power See rating plate
Heater power See rating plate
Water pressure 0,1–1 MPa
1–10 kp/cm
2
10–100 N/cm
2
Material for the drum and dispenser Stainless steel
Housing material Hot-dip galvanized and powder coated sheet metal, or
stainless steel sheet (depending on model)
Water connection 1.5 m pex hose
Drain hose 1.6 m polypropylene hose
