WM 110
ELECTRICAL COMPONENTS
1 Timer
The timer has a preselecting facility. Only the eight starting points can be
set, after which the timer mechanism steps the cams to the correct
position that has been selected.
2 Thermostat
The thermostat is combined with the main onloff switch. A manual safety
catch, which can be disengaged, must be pressed in, when turning the
thermostat to higher temperatures.
3 Motor
The motor is a 8-pole combined capacitor motor and a commutator
motor. The 8-pole section drives the motor at normal wash speed with
reversing, while the commutator section produces the 900 rpm and
1400 rpm spin speeds. The motor is protected by a built-in thermal
overload cutout.
4 Outlet pump
The outlet pump is combined with a integral button trap, which can be
cleaned by the customer.
5 Inlet valve
The inlet valve provides three-way control of the water to direct it to the
appropriate inlets for 1) prewash and rinses, 2) main wash and 3) fabric
conditioner. A fourth inlet valve can be fitted for machines intended for
use with hot water supplies.
6 Heater element
The heater elements are of 1200 W and 1800 W repectively. Machines
with heater contactor have elements with fuse.
7 Capacitor
The capacitor is of 16 µF, and is mounted together on the electrical
component tray.
8 Level switch
There are two level switches with two levels each:
• Normal level for wash and rinse and high level for Super rinse,
wool program and cool down.
• Spin protection level, advances the timer over the spin, if the the
water is not pumped out. Overfill level; cuts the current to the inlet valves
and starts the outlet pump.
