ASM Zip-Clean 2730B - Page 3

3309424
Component Identification
D
Gun and wand
High Pressure Hose Con-
nection and Garden Hose
Connection
Hose
On/Off Engine Switch (side)
Hydraulic Fluid Fill
Engine Oil Fill
Pressure Unloader
Adjustment Knob
Tip Storage
garden hose
connection
high pressure hose
connection
Oil Level Site Gage
