1. Follow Pressure Relief Procedure, page 5.
Chemical Injector Operation
2. Insert chemical filter (attached with clear tubing to
chemical injector) into container of chemical. Insert
brass coupler into chemical injector.
3. Install the black, large–orifice, chemical tip. (Installing
and Changing Spray Tips, page 10).
NOTE: The large orifice of chemical tip causes a drop in
pressure that actuates chemical injector. Changing back to
a small orifice spray tip deactivates the chemical injector and
produces high pressure for rinsing. The chemical filter can
be left in the chemical container during high–pressure use.
To regulate flow rate of chemical, turn chemical adjustment
knob on the injector.
