Alarm Connector Pinout
The CO alarm connector pinout is provided in the table below.
Use a Phillips #1 screwdriver to remove the two screws that secure the cover plate over the alarm connector.
Table 1: DB15S CO Alarm Connector Pinout
SignalAlarm LevelPin
Normally OpenMinor1
Normally Closed2
Not connected
—
3
Normally OpenMajor4
Normally Closed5
Not connected
—
6
Normally OpenCritical7
Normally Closed8
Minor, CommonMinor9
Not connected
—
10
Not connected
—
11
Major, CommonMajor12
Not connected
—
13
Not connected
—
14
Critical, CommonCritical15
Electrical Characteristics
Each of the three dry-contact, Form C relay switches is rated to support a maximum switching current of
1A@30VDC.
Never connect a high voltage/high current device such as an audible alarm/siren or incandescent lamp
directly to the EO alarm connector.
