X570D4U-2L2T / X570D4U
8 9
English
No. Description
34 Chassis ID3 Jumper (CHASSIS_ID3)
(Reserved for BOM option)
35 Front LAN LED Connector (LED_LAN_3_4)
(X570D4U-2L2T only)
36 Front VGA Header (FRNT_VGA1)
*For DIMM installation and conguration instructions, please see p.21 (Installation of Memory Modules
(DIMM)) for more details.
