Page #146 background imageLoading...
Page #146 background image
142
Bahasa Indonesia
** Mendukung Intel® Volume Management Device (VMD)
** Mendukung SSD NVMe sebagai disk boot
** Mendukung Kit ASRock U.2
RAID
•
Mendukung RAID 0, RAID 1, RAID 5 dan RAID 10 untuk
perangkat penyimpanan SATA
Konektor
•
1 x Addressable LED Header
* Mendukung total Strip LED hingga 5V/3A, 15W
•
1 x Konektor Kipas CPU (4-pin)
* Konektor Kipas CPU mendukung kipas CPU dengan daya kipas
maksimum 1A (12W).
•
1 x Konektor Kipas Chassis (4-pin)
* Konektor Kipas Sasis mendukung kipas sasis dengan daya kipas
maksimum 1A (12W).
•
1 x Konektor Kipas Chassis/Pompa Air (4-pin) (Kontrol Kecepatan
Kipas Pintar)
* Chassis/Kipas Pompa Air mendukung kipas berpendingin air dengan
daya kipas maksimum 2A (24W).
* CHA_FAN1/WP dapat mendeteksi otomatis jika kipas 3-pin atau
4-pin sedang digunakan.
•
1 x Konektor Daya ATX 24 pin
•
1 x Konektor Daya 8 pin 12V
•
1 x Konektor Audio Panel Depan
•
1 x Header USB 2.0 (Mendukung 2 port USB 2.0) (Mendukung
Perlindungan dari ESD)
•
1 x Header USB 3.2 Gen1 (Mendukung 2 port USB 3.2 Gen1)
(Mendukung Perlindungan dari ESD)
•
1 x Header Tipe C USB 3.2 Gen1 Panel Depan (Mendukung
Perlindungan ESD)
Fitur BIOS
•
AMI UEFI Legal BIOS dengan dukungan GUI multibahasa
•
ACPI 6.0 Kompatibel dengan aktivitas pengaktifan
•
Dukungan SMBIOS 2.7
•
CPU Core/Cache, CPU GT, DRAM, VCCIN AUX, +1,05V PROC,
+1,8V PROC, +0.82V PCH , Multi penyesuaian Tegangan +1,05V
PCH

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK B660M-ITX/ac and is the answer not in the manual?

ASROCK B660M-ITX/ac Specifications

General IconGeneral
Processor socketLGA 1700
Processor manufacturerIntel
Compatible processor seriesIntel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Maximum number of SMP processors1
Audio chipRealtek ALC897
Component forPC
Motherboard chipsetIntel B660
PC health monitoringCPU, FAN, Temperature, Voltage
Audio output channels7.1 channels
Motherboard form factormini ITX
Windows operating systems supportedWindows 10 x64, Windows 11 x64
ECCYes
Memory slots typeDIMM
Number of memory slots2
Supported memory typesDDR4-SDRAM
Maximum internal memory64 GB
Supported memory clock speeds5000 MHz
RAID levels0, 1, 5, 10
Supported storage drive typesHDD & SSD
Supported storage drive interfacesSATA III
Cables includedSATA
DisplayPort version1.4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity0
Number of SATA III connectors4
Maximum resolution7680 x 4320 pixels
Parallel processing technology supportNot supported
LAN controllerIntel® I219-V
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Ethernet interface typeGigabit Ethernet
Harmonized System (HS) code84733020
Weight and Dimensions IconWeight and Dimensions
Width170 mm
