Motherboard Layout
Intel
H97
DDR3_A2 (64 bit, 240-pin mod ule)
DDR3_A1 (64 bit, 240-pin mod ule)
DDR3_B2 (64 bit, 240-pin mod ule)
DDR3_B1 (64 bit, 240-pin mod ule)
ATX12V1
Super
I/O
USB 2.0
T: USB0
B: US B1
Ps2
Keyboard/
Mouse
ATXPWR1
1
USB3_4_5
LAN
PCIE2
Top:
RJ-45
USB 3.0
T: USB2
B: USB3
Top:
Central/Bass
Center:
REAR SP K
Top:
LINE IN
Center:
FRONT
Bottom:
Optical
SPDIF
Bottom:
MIC I N
PCIE4
PLE D1
1
1
SPE AKER 1
HDL ED R ESE T
PLE D PW RBT N
PANE L1
1
USB6_ 7
1
USB4_ 5
1
COM1
1
1
HD_AU DI O1
H97 PERFORMANCE
SATA3 _0
PCIE1
CHA_FAN1
CHA_FAN2
CHA_FAN3
PCI1
PCI2
RoHS
8
11
9
10
13
1516
17
19
21
14
12
24
2
3
5
7
6
1
29
22
USB 2.0
T: USB2
B: US B3
HDMI
FATAL TY 1
Purity
Sound 2
TM
VGA1
DVI1
SATA3 _3
SATA3 _1
SATA3 _4
SATA3 _2
SATA3 _5
PCI3
PCIE3
USB 3.0
T: USB0
B: US B1
64Mb
BIOS
BIOS_ B1
64Mb
BIOS
BIOS_ A1
BIO S_B_ LED 1
BIOS_ SE L1
1
27
CPU_FAN1
CPU_FAN2PWR_FAN1
CMOS
Battery
BIO S_A_ LED 1
CLRMO S1
1
PCIE_PW R1
1
TPMS 1
4
1820
25
26
28
T B1
23
RoHS
PCI Express 3.0
Front USB 3.0

ASROCK Fatal1ty H97 Performance Series Specifications

General

Chipset	Intel H97
Socket	LGA 1150
Form Factor	ATX
Max Memory	32GB
Memory Standard	DDR3 1600/1333
PCI Express x1	2
SATA Ports	6 x SATA 6Gb/s
LAN	Intel I218V Gigabit LAN
Memory Slots	4
M.2	1
USB 3.0 Ports	6 x USB 3.0 (2 front, 4 rear)
USB 2.0 Ports	6
Audio	Realtek ALC1150 7.1-Channel High Definition Audio
RAID Support	RAID 0, 1, 5, 10
Multi-GPU Support	AMD Quad CrossFireX
