ASROCK Fatal1ty H97 Performance Series User Manual

Fatal1ty H97 Performance Series
3
English
I/O Panel
No. Description No. Description
1 USB 2.0 Ports (USB01) 9 Front Speaker (Lime)**
2 D-Sub Port 10 Microphone (Pink)
3 Fatal1ty Mouse Port (USB2) 11 Optical SPDIF Out Port
4 USB 2.0 Port (USB3) 12 USB 3.0 Ports (USB3_23)
5 LAN RJ-45 Port* 13 USB 3.0 Ports (USB3_01)
6 Central / Bass (Orange) 14 HDMI Port
7 Rear Speaker (Black) 15 DVI-D Port
8 Line In (Light Blue) 16 PS/2 Mouse/Keyboard Port
1 2 4
3
5 7
101116 12131415
6
9
8

ASROCK Fatal1ty H97 Performance Series Specifications

General

Chipset	Intel H97
Socket	LGA 1150
Form Factor	ATX
Max Memory	32GB
Memory Standard	DDR3 1600/1333
PCI Express x1	2
SATA Ports	6 x SATA 6Gb/s
LAN	Intel I218V Gigabit LAN
Memory Slots	4
M.2	1
USB 3.0 Ports	6 x USB 3.0 (2 front, 4 rear)
USB 2.0 Ports	6
Audio	Realtek ALC1150 7.1-Channel High Definition Audio
RAID Support	RAID 0, 1, 5, 10
Multi-GPU Support	AMD Quad CrossFireX
